Engineering Technical Specifications
| Parameter | Engineered Specification Standard |
|---|---|
| Tooling Type | Indexable Multi-Insert System |
| Insert Fitting | Precision Wire-EDM Insert Pockets |
| Substrate | Hardened Alloy Steel Body |
| Coating | PVD Multi-layer Coating |
| Application | Automotive Component & Production Machining |
Technical Documentation & CAD Downloads
Indexable Customized Cutting Tools Datasheet
PDF • 2.4 MB
SSNV Master Tool Catalogue
PDF • 18 MB
Tooling Tolerances Spec
DIN 3968 • 1.1 MB
